Zebra ZT610 Industrial Printer (ZT61A46-T2E0100Z)

The Zebra ZT610 is a 4-inch industrial label printer from Zebra's ZT600 Series – the successor to the legendary Xi Series – built for 24/7 high-volume labelling in manufacturing, warehouses, transport and logistics. Its all-metal construction and fanless thermal management keep it printing even in dusty, demanding environments, while the bright 4.3-inch colour display shows the printer status at a glance. It prints thermal transfer and direct thermal labels at 600 dpi, up to 104 mm wide and at up to 152 mm/s (6 ips). This version, ZT61A46-T2E0100Z, is fitted with the factory-installed rewinder, which rewinds a full roll of printed labels on a 76 mm core – or peels the labels and rewinds the liner; it connects via USB 2.0, USB Host, RS-232 serial, Gigabit Ethernet and Bluetooth 4.1. As the ZT610 Micro Label Printer, it offers up to 50% more precise registration than a standard ZT610 600 dpi and prints labels as small as 3 mm on media from 12 mm wide. EU and UK power cords are included; the USB interface cable must be ordered separately.

Key Features

• Built for 24/7 operation – all-metal, heavy-gauge structural components and built-in thermal management without vents or cooling fans keep dust and debris out for years of continuous, trouble-free printing.
• Bright 4.3-inch colour display – intuitive icon menus for settings, languages and connectivity; the display turns red in an error state so the printer status is visible from a distance, and colour-coded touch points and an illuminated media path speed up loading.
• Thermal transfer and direct thermal – 450 m ribbons mean fewer changes; print smudge-proof, long-life labels on paper, polyester and polypropylene, or switch to direct thermal for short-life labels.
• Micro Label Printer – a high-precision version of the 600 dpi ZT610 with up to 50% more precise registration, labels as small as 3 mm and media from 12 mm wide; enhanced for integration with automated labelling systems.
• Full-roll rewind – rewinds printed labels on a 76 mm core for later application with an applicator or labeller, or peels labels and rewinds the liner.
• Fully connected – USB 2.0, USB Host, RS-232, Gigabit Ethernet and Bluetooth 4.1 as standard; two open slots for Wi-Fi 6, parallel, a second Ethernet or an applicator interface card.
• Easy maintenance – quick-change printhead with a tool-free socket, single-knob adjustment of the fused upper and lower media sensors, printhead pressure toggles with a scale, and QR codes that link to error-specific help videos.
• Zebra DNA and Link-OS – ZPL / ZPL II and XML printing, Printer Profile Manager Enterprise, MDM connectors (Workspace ONE, SOTI Connect) and Cloud Connect for secure remote management; ENERGY STAR certified.

Ideal Applications

• Electronics – component, circuit board and serial number labels as small as 3 mm
• Healthcare and laboratories – vial, test tube and small specimen labels
• Jewellery and cosmetics – tiny price and product labels
• Automated labelling – print-and-apply lines that need precise registration
• Manufacturing – work-in-process and traceability labels for small parts

All ZT610 / ZT620 Versions

The highlighted row is the version you are currently viewing.

Technical Specifications

Which ZT600 printer should you choose? The ZT610 prints up to 104 mm wide in 203, 300 or 600 dpi – plus the 600 dpi Micro Label Printer version for labels as small as 3 mm; the ZT620 prints up to 168 mm wide (203 or 300 dpi) for large labels such as A5 shipping or GHS drum labels. Then pick the media handling – tear-off, cutter or rewinder – the 4.3-inch colour display or colour touch display, and Wi-Fi or UHF RFID if you need it. Compare other models in our Industrial Label Printers collection or contact our team for volume pricing.
