| Dalies numeris | 99-158A015-2102 |
| Modelis | TSC DA220 (DA Series) |
| Spausdintuvo tipas | 4-inch desktop direct thermal label printer |
| Spausdinimo būdas | Direct thermal (no ribbon) |
| Skyra | 203 dpi (8 dots/mm) |
| Spausdinimo greitis | Up to 152 mm/s (6 ips) |
| Didž. spausdinimo plotis | 108 mm (4.25") |
| Didž. spausdinimo ilgis | 25,400 mm (1,000") |
| Laikmenos plotis | 19–114 mm (0.7"–4.5") |
| Laikmenos storis | 0.055–0.19 mm (2.16–7.48 mil) |
| Ritinėlio skersmuo | 127 mm (5") OD inside the printer; up to 214 mm (8.4") OD on 3" core with the optional external roll mount |
| Šerdies dydis | 25.4–38 mm (1"–1.5") |
| Laikmenų tipai | Continuous, die-cut (gap), black mark, fanfold, notched (outside wound); direct-thermal media; label length 10 mm – 25,400 mm |
| Jutikliai | Transmissive gap sensor, black-mark reflective sensor, head-open sensor |
| Sąsajos | PCBA2: USB 2.0 (high speed), Ethernet 10/100 Mbps |
| Belaidis ryšys | None |
| Procesorius | 32-bit RISC CPU |
| Atmintis | 64 MB DRAM, 128 MB Flash |
| Realaus laiko laikrodis | Standard |
| Spausdintuvo kalbos | TSPL-EZD (EPL, ZPL, ZPL II and DPL compatible) |
| Šriftai / simbolių rinkiniai | 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed scalable font; 0/90/180/270° rotation |
| Brūkšniniai kodai | 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC 2(5)-digit add-on, MSI, Plessey, Postnet, RSS-Stacked, GS1 DataBar, Code 11, China Post; 2D: PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec |
| Ekranas | No LCD – 1 three-colour status LED (green/amber/red), 1 feed button, power switch |
| Laikmenos apdorojimo parinktys | Tear-off (standard); dealer options: peel-off module, guillotine cutter (full or partial cut), linerless cutter / linerless tear kits |
| Priedai | 1.5" core adaptor; external roll mount (214 mm OD, 3" core); KP-200 Plus keyboard display unit (serial) |
| Tvarkyklės ir programinė įranga | Windows drivers and TSC labeling software (CD / free download), TSC Console |
| Maitinimas | External universal switching power supply: 100–240 V AC, 50–60 Hz input; 24 V DC, 2.5 A, 60 W output |
| Matmenys (P × G × A) | 172 × 195 × 165 mm (W × D × H) |
| Svoris | 1.5 kg |
| Spalva | Black |
| Korpusas | Double-walled plastic clamshell |
| Darbinė temperatūra | 5–40 °C, 25–85% RH non-condensing |
| Laikymo temperatūra | −40–60 °C, 10–90% RH non-condensing |
| Sertifikatai | FCC Class A, CE Class A, RCM, CB, CCC, ENERGY STAR, KC, BIS, UL, EAC; RoHS, WEEE |
| Garantija | Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first) |
| Pakuotės turinys | TSC DA220 printer (203 dpi, USB 2.0, Ethernet 10/100), external universal power supply (24 V DC, 60 W), power cord (EU Schuko plug), USB cable, Windows labeling software (CD or download), quick start guide – labels NOT included |
