The TSC MX240P is a heavy-duty 4-inch industrial thermal transfer printer for high-volume enterprise applications. Its die-cast aluminium design, fast 536 MHz processor and TSC's Thermal Smart Control print technology deliver clean, high-quality barcodes at up to 457 mm/s (203 dpi). It takes 203 mm (8-inch) label rolls on 76 mm cores and 600 m ribbons, has a 4.3-inch colour touch LCD and connects via USB, RS-232, Ethernet and two USB host ports as standard. This version, 99-151A001-000M, comes with the standard tear-off bar – optional peel-off, cutter and internal rewinder kits are available.
📦 What's in the box – 99-151A001-000M
- ✅ TSC MX240P label printer – 203 dpi, built-in power supply 100–240 V
- ✅ Power cord – UK plug (type G)
- ✅ USB cable – USB A to B, for connecting to your PC
- ✅ Windows labeling software and drivers – on CD – also a free download from TSC
- ✅ Setup guide – printed quick start guide
- ❌ Labels – NOT included
- ❌ Thermal transfer ribbon – NOT included
- ❌ Ethernet (LAN) cable – NOT included
✅ Ready to print out of the box – the power supply is built in, and the power cord and USB cable are included; you only need labels and a thermal transfer ribbon (direct thermal labels print without a ribbon). For a network connection, use the built-in Ethernet port with a standard RJ45 patch cable (not included).
💡 Useful extras: matching labels (TSC 38-T102102-10LF or Zebra 76180); ribbons up to 600 m (TSC P159049-001 or TSC P159079-001); upgrade options: peel-off kit (TSC 98-0510016-00LF), cutter (TSC 98-0510058-10LF), internal rewinder kit (TSC 98-0510075-00LF), KP-200 Plus keyboard display (TSC KP-200 Plus).
Key Features
- Heavy-duty die-cast aluminium design – die-cast print mechanism and frame with an aluminium cover and a large clear media window, made for high-volume enterprise use.
- 4.3-inch colour touchscreen – intuitive multi-language menus with touch and six-button operation, plus LED status indicators.
- Thermal transfer and direct thermal – up to 457 mm/s at 203 dpi with a maximum print width of 104 mm.
- Large media capacity – label rolls up to 203 mm in diameter on 76 mm cores, media 20–114 mm wide; continuous, die-cut, black-mark, notched and fanfold media.
- 600 m ribbons – long ribbons on a 1-inch core mean fewer changes; ribbons coated inside or outside both work.
- Connected as standard – USB 2.0, RS-232, 10/100 Ethernet and two front USB host ports for a scanner or keyboard; optional GPIO + parallel interface and slot-in Wi-Fi.
- Thermal Smart Control – TSC print technology for clean, high-quality barcodes, precise media positioning, pre-printed label identification and a ribbon and media capacity monitor.
- Plug-and-play firmware – the TSPL-EZ printer language with EPL and ZPL emulation for easy integration into existing systems.
- Upgrade options – peel-off kit, guillotine or rotary cutter, internal rewinder, GPIO + parallel interface, slot-in Wi-Fi and KP-200 Plus or KU-007 Plus keyboards.
Ideal Applications
- Manufacturing – work-in-process, product marking, compliance and industrial-duty labels
- Transport and logistics – packing, order fulfilment, shipping and receiving, pallet labels
- Warehousing – inventory, location and asset labels
- Healthcare and pharma – specimen, pharmaceutical and asset tracking labels
- Retail and food – product, price, weighing scale and food packaging labels
All MX240P Versions
The highlighted row is the version you are currently viewing.
| Part Number | Model | Resolution | Media Options | |
|---|---|---|---|---|
| 99-151A001-7ALF | TSC MX240P | 203 dpi | Internal rewinder | View product |
| 99-151A001-000M (this version) | TSC MX240P | 203 dpi | Tear-off | Viewing |
Technical Specifications
| Part Number | 99-151A001-000M |
|---|---|
| Model | TSC MX240P (MX240P Series) |
| Printer Type | 4-inch industrial thermal transfer label printer – MX240P Series |
| Construction | Die-cast print mechanism and frame; aluminium cover with large clear media view window |
| Print Method | Thermal transfer and direct thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 457 mm/s (18 ips) |
| Max Print Width | 104 mm (4.09") |
| Max Print Length | 25,400 mm (1,000") |
| Min. Label Length | 3 mm |
| Media Width | 20–114 mm (0.78"–4.49") |
| Media Thickness | 0.076–0.305 mm (2.99–12.01 mil) |
| Roll Diameter | 203.2 mm (8") OD |
| Core Size | 76.2 mm (3") |
| Media Types | Continuous, die-cut, black mark, fanfold, notched (outside wound) |
| Sensors | Gap transmissive (position adjustable), black mark reflective (position adjustable), head open, ribbon end, ribbon encoder |
| Ribbon | Max. 600 m, max. OD 90 mm, 1" (25.4 mm) core, ink coated outside or inside; width 40–115 mm |
| Media Options | Tear-off (standard); options: peel-off kit, internal rewinding kit (full roll), guillotine or rotary cutter |
| Interfaces | USB 2.0, RS-232, internal Ethernet 10/100 Mbps, 2 × USB host (front, for scanner or PC keyboard); option: GPIO + parallel |
| Wireless | None as standard; option: slot-in Wi-Fi 802.11a/b/g/n |
| Processor | 32-bit RISC CPU (536 MHz) |
| Memory | 512 MB Flash, 512 MB SDRAM; microSD card reader for up to 32 GB |
| Real-Time Clock | Standard |
| Printer Languages | TSPL-EZ (with EPL and ZPL emulation) |
| Fonts / Character Sets | 8 alphanumeric bitmap fonts; Monotype Imaging true type font engine with CG Triumvirate Bold Condensed scalable font; 0/90/180/270° rotation |
| Barcodes | 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC 2/5-digit add-on, MSI, Plessey, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, China Post; 2D: PDF417, MaxiCode, DataMatrix, QR Code, Aztec |
| Display | 4.3" 16-bit colour LCD (480 × 272 pixels) with backlight, resistive touchscreen; power switch, 6 buttons (Menu, Pause, Feed, Up, Down, Select) |
| Options | Peel-off kit, internal rewinder, guillotine / rotary cutter, GPIO + parallel interface, slot-in Wi-Fi, KP-200 Plus keyboard, KU-007 Plus smart keyboard |
| Drivers & Software | Labeling software and Windows drivers; TSC Console |
| Power Supply | Internal universal switching power supply: 100–240 V AC, 4–2 A, 50–60 Hz; output 243 W total |
| Dimensions (W × D × H) | 300 × 510 × 393 mm |
| Weight | 18 kg |
| Operating Temperature | 5–40 °C, 25–85% RH non-condensing |
| Storage Temperature | −40–60 °C, 10–90% RH non-condensing |
| Certifications | FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/Safety, CCC, CB, BIS, EAC, ENERGY STAR; RoHS, WEEE |
| Warranty | Printer: 2 years; printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first) |
| In the Box | TSC MX240P printer (203 dpi, built-in power supply), power cord (UK type G plug), USB cable, Windows labeling software and drivers (CD), quick start guide – labels, ribbon and Ethernet cable NOT included |
Which MX240P should you choose? With 203 dpi it is ideal for barcodes, shipping and warehouse labels. Choose the standard tear-off version or the version with factory-installed internal rewinder. Compare other models in our Industrial Label Printers collection or contact our team for volume pricing.
