The Newland HR12 Anchoa is a practical, user-friendly entry-level corded 1D barcode scanner at a very competitive price. Its 1500-pixel CCD sensor and Newland's 1D decoder chip read all major 1D barcodes at 300 scans per second – standard EAN-13 codes from 5 cm up to 65 cm – while drawing only 55 mA. Lightweight, IP41-rated and backed by a 5-year warranty, it is an easy choice for everyday checkout and stock work. This version, NLS-HR1250-70, is supplied with a 2 m USB cable that is permanently attached to the scanner – simply plug it into a USB port and start scanning.
📦 What's in the box – NLS-HR1250-70
- ✅ Newland HR12 Anchoa scanner – black, 1D linear imager (CCD), USB
- ✅ USB cable (attached) – 2 m, permanently connected to the scanner (not detachable) – plug and play, powered via the USB port, no power supply needed
- ❌ Stand – not included
💡 Want to keep the scanner within reach without taking up desk space? Add the Newland NLS-STD-WM001 wall mount clip. Please note: the HR12 Anchoa has a fixed USB cable and no stand is offered for it – if you need hands-free scanning with a stand, an RS-232 connection or a replaceable cable, choose the Newland HR11 Aringa instead, e.g. the NLS-HR1150P-30F kit with a foldable smart stand.
Key Features
- 1D CCD scanning – a 1500-pixel CCD sensor with red LED illumination reads all major 1D barcodes, including EAN/UPC, Code 128, Code 39, Interleaved 2 of 5 and GS1 DataBar. Please note: it does not read 2D codes such as QR codes or Data Matrix.
- Fast and responsive – 300 scans per second and a 40° field of view; 13 mil EAN-13 codes are read from 5 to 65.5 cm, with generous reading angles (pitch and skew ±60°).
- Plug-and-play USB – the attached 2 m USB cable connects directly to a PC, laptop or POS system and also powers the scanner, so no separate power supply is needed.
- Flexible scan modes – trigger, automatic sense, continuous and command-trigger modes let you adapt the scanner to your workflow.
- Ergonomic and lightweight – the compact design weighs just 130 g including the cable and is easy to handle all day.
- Energy-efficient – an operating current of only 55 mA (21 mA in standby) keeps power consumption low.
- Reliable, with a 5-year warranty – IP41 protection, ESD protection up to ±10 kV (air discharge) and operation from −20 °C to 60 °C; backed by a 5-year warranty.
Ideal Applications
- Retail chains and point-of-sale checkouts
- Inventory counting and warehouse management
- Express delivery and parcel services
- Food traceability and manufacturing
- Healthcare and hospitality front desks
- Electricity meter reading
Technical Specifications
| Part Number | NLS-HR1250-70 |
|---|---|
| Model | Newland HR12 Anchoa (HR1250) |
| Scanner Type | Corded handheld 1D linear imager (does not read 2D codes) |
| Image Sensor | 1500-pixel linear CCD |
| Light Source | Red LED, 610–640 nm |
| Field of View | 40° (horizontal) |
| Scan Range | EAN-13 13 mil: 50–655 mm; Code 39 5 mil: 55–165 mm |
| Reading Angles | Roll 30°, pitch ±60°, skew ±60° |
| Minimum Print Contrast | 30% |
| Scan Rate | 300 scans per second |
| Scanning Modes | Trigger, sense (automatic), continuous, command trigger |
| Symbologies | All major 1D symbologies: EAN-8, EAN-13, UPC-A, UPC-E, ISBN, ISSN, Code 128, Code 39, Code 93, Code 11, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, MSI-Plessey, Plessey, GS1 DataBar |
| Decoding | Newland 1D decoder chip (0110) |
| Host Interfaces | USB |
| Cable | USB, 2 m, permanently attached (not detachable) |
| Reading Indicators | Beeper, LED indicator |
| Color | Black |
| Housing Material | PC, ABS |
| Dimensions | 163 × 68.4 × 58.5 mm (L × W × H) |
| Weight | 130 g (including USB cable) |
| Input Voltage | 5 VDC ± 5% |
| Current Draw | Operating: 55 ± 5 mA; standby: 21 ± 2 mA (at 5 V) |
| Environmental Sealing | IP41 |
| Electrostatic Discharge | ±8 kV (contact discharge), ±10 kV (air discharge) |
| Operating Temperature | −20 °C to 60 °C |
| Storage Temperature | −40 °C to 85 °C |
| Humidity | 5–95% RH, non-condensing |
| Certifications | FCC Part 15 Class B, CE EMC Class B, RoHS |
| Warranty | 60 months |
| In the Box | HR12 Anchoa scanner, USB cable (2 m, permanently attached – not detachable) |
Need to read QR codes or other 2D codes? Choose a 2D scanner instead. Compare other models in our Handheld Barcode Scanners collection or contact our team for volume pricing.
